6222Z-R RTL8722CSM
RTL8722CSM is a highly integrated single-chip low power single bands (2.4GHz) Wireless LAN (WLAN) and Bluetooth Low Energy (BLE 5.0) communication controller. It consists of a high performance MCU (Armv8-M, Cortex-M33 instruction set compatible) called Real-M300 (or KM4 thereafter) and a low power MCU (Armv8-M, Cortex-M23 instruction set compatible) called Real-M200 (or KM0 thereafter), WLAN (802.11 b/g/n) MAC, an 1T1R capable WLAN baseband, RF, Bluetooth and peripherals.
High speed connectivity interfaces, SDIO and USB are provided. Also audio codec, key-scan and touch keys integrated. Flexible design configures GPIO to different functions.
6222Z-R integrates internal memories for complete Wi-Fi protocol functions.
General
Supports 20MHz/40MHz up to MCS7,802.11 b/g/n 1x1, 2.4GHz
Host Interface
Support SDIO 2.0/SD/USB/SPI/UART/I2C/USI/IR/SGPIO
Bluetooth Features
Support Bluetooth 5.0
High power mode (8dbm, shares the same PA with Wi-Fi)
Internal co-existence mechanism between Wi-Fi and BT to share the same antenna
Model No. | 6222Z-R | Main Chipset | RTL8722CSM |
Interface | UART,USB,SD, SDIO ,SPI,I2C…. | Wi-Fi Standard | IEEE 802.11b/g/n+BLE5.0 |
Data Rate | 72.2Mbps | Certification | RoHS |
RF Antenna | On-board Antenna | OS Supported | Android /Linux/ Win CE /iOS /XP/WIN7/WIN10 |
Operating Frequency | 2.400～2.4835GHz | Operating Voltage | 3.3V |
Dimension | L20 x W28 x H3.35 mm | RF Chain | 1T1R |
Operating Temperature | -20°C to 85°C | Storage Temperature | -40°C to 125°C |
Ordering Information
Part No. | Description |
FG6222ZRXX-00 | RTL8722CSM,802.11b/g/n,Wi- Fi+BLE5.0,1T1R,20X28mm,Uart+USB, with shielding |
