H2355E-U Wi-Fi Module

H2355E-U Wi-Fi Module
SV6355
Single-band 1x1
802.11b/g/n/ax
BLE5.0
2.4G
1T1R
USB
12.2*13
Contact us for HDK, SDK and EVB
Pre-certification available: SRRC
Availability:
  • 2.4G

  • BT5.0 and above

  • 1T1R

  • Select

  • USB Interface

Product Name

H2355E-U  SV6355


SV6355
Single-band 1x1 1T1R
802.11b/g/n/ax
BLE5.0
2.4G
USB
12.2 x 13 x1.62 mm



Details Information

 Inroduction

The H2355E-U is a fully integrated SoC with 2.4GHz band 1T1R 11b/g/n/ax+BLE Wi-Fi, Bluetooth Low Energy 5.0, and MCU.support Single-chip IEEE 802.11b/g/n/ax WLAN with USB Interface.

The H2355E-U WLAN SoC is designed to support IEEE 802.11 b/g/n/ax single spatial stream It is designed with the state of-the-art techniques and process technology to achieve low power consumption and high throughput performance to address the requirement of mobile and handheld devices.

 Features

General Features

IEEE 802.11 b/g/n/ax+BLE5.0 compliant

Support 802.11n 20/40MHz up to MCS7 150Mbps

Support 802.11ax 20/40MHz up to MCS9 229Mbps

Concurrent AP + STA supported

including Wi-Fi WPA3, the SV6355 builds strong secure system products for smart home applications.


WLAN Interface

Support PCI Express 2-lane-g2 or 1-lane-g3


Bluetooth Features

The SV6355 supports BLE Master, Slave, Advertiser, Scanner roles. It supports standard HCI in BLE side.

Bluetooth 5.0 Low Energy

IG Mesh v1.01 supported

 Applications

OTT/IPTV/DVB/Set-top Box, Tablet PC, Advertising Machine,Intelligent TV, IPC/NVR, Industrial Control Equipment,Car Recorder,Intelligent Doorbell, Intelligent Projector, Virtual Reality, VR/AR, Wireless Storage, Printer, POS Machine, Electronic Scale,Vehicle Front/Rear End, Drone, Robot, HDMI Transmitter,Smart Gateway, Education,Toys, Lighting Lamps, Intelligent Street Light, Intelligent Home Appliances/Home Appliances Instrumentation (Water, Electricity, Gas), Smart City and other Consumer Electronic Products.

 Block Diagram

1683359888769


 Parameters

Model No.

H2355E-U

Main Chipset

SV6355

BT Interface

USB

Wi-Fi Standard

IEEE802.11b/g/n/ax+BLE5.0

Data Rate

802.11n 20/40MHz: MCS7 150Mbps

802.11ax 20/40MHz: MCS9 229Mbps

Certification

RoHS,REACH

Product Description

Support Wi-Fi functionalities

OS Supported

Android /Linux/ Win CE /iOS /XP/WIN7/WIN10

Operating Frequency

2.412 GHz ~ 2.484 GHz (2.4 GHz ISM Band)

Operating Voltage

3.3V

Dimension

L x W x H: 12.2 x 13 x1.62 mm

RF Chain

1T1R

Operating Temperature

-20°C to 70°C

Storage Temperature

-40°C to 85°C


 Ordering Information

Part No.

Description

FGH2355EUX-00

SV6355/2.4G/802.11b/g/n/ax+BLE5.0 1T1R,USB,12.2*13

FGH2355EUX-01 SV6355/2.4G/802.11b/g/n/ax BLE5.0 1T1R,USB,12.2*13,带 天线座版本
